This simple rhythmic light circuit uses a 110 V to 220 V transformer and can hold a good number of lamps. Note, however, that there is no isolation from the sound equipment, which should be achieved by using a small 12 V x 500 mA to 110 V transformer. The triac should be equipped with a heat sink. The circuit is from a 1986 documentation.
| Clique na imagem para ampliar |
