Simple sound bridge (CB6069E)

Details: Written by: Newton C. Braga

This simple bridge circuit can be used for impedance or resistance measurement using a high impedance earphone as an indicator. The circuit is from an American 80's documentation.

| Clique na imagem para ampliar |
