This circuit was found in a documentation from 1948. There are 5 valves with push-pull output. The source uses a transformer, and the indicated application is with turntables.
| Clique na imagem para ampliar |
25W Amplifier (T1145E)
- Details
- Written by: Newton C. Braga
