Found in the 1975 RCA tube manual, this circuit appears elsewhere in this section. The circuit uses contemporary components and is powered by the power grid.
| Clique na imagem para ampliar |
Code Practice Oscillator (T1541E)
- Details
- Written by: Newton C. Braga
