12W Phonographic Amplifier and Compressor (T499E)

Details
Written by: Newton C. Braga



This 8-tube amplifier with 12 W output was found in an American publication from 1947. The output is in counterphase with pentode tubes.














| Clique na imagem para ampliar |




| Clique na imagem para ampliar |
