10 10W tone control amplifier TDA2209 (CB15247E)

Details
Written by: Newton C. Braga



In addition to tone control, this circuit of the SGS 1982 linear integrated circuit manual has a loudness control. The supply must be made with a 24V voltage source.




| Clique na imagem para ampliar |
