Phase Shift Oscillator (CB14952E)

Details
Written by: Newton C. Braga



This traditional circuit generates a 200 Hz sinusoidal signal. The frequency depends on the capacitors and the transistor can be a BC548. We found this circuit in a 1979 documentation.




| Clique na imagem para ampliar |
