This 1992 circuit operates in the range of cordless phones used at the time. The circuit is based on an integrated circuit that is uncommon today; The transmitting coil has 30 + 30 turns of wire 28 in a ferrite rod.
| Clique na imagem para ampliar |
1.78 MHz Telephone Transmitter (CB16689E)
- Details
- Written by: Newton C. Braga
