This experimental TTL circuit is from 1992 documentation. It produces programmed sounds set in the 10 k potentiometers. These components control an oscillator with two transistors whose basic frequency depends on the capacitor. The unijunction transistor generates the drive sequence. The supply must be made with 5 V.
