Amplifier MFC9010 (CB20027E)

This integrated amplifier was used in televisions from the 70s, with good sensitivity characteristics. The circuit was powered with 9 V.

| Clique na imagem para ampliar |

Damped tone generator (CB8842E)
This circuit uses an unusual electromechanical component: a mechanical blade resonator. The...
Transistor Amplifier (CB18859E)
This circuit from a Japanese publication in 1968 uses germanium transistors from the time like the...
Operational power VCO (CB8779E)
Found in a 90s Electronic Design, this circuit can provide a relatively high-power output. The basic...
