STEMTera Mounting Plates with Embedded Hardware

Details: Written by: Newton C. Braga

September 2017 - SparkFun offers through Mouser Electronics its protboard solderless board that have built-in hardware compatible with Arduino-compatible shields. The board features exposed ATmega32 pins for easy project development.

Click here and see more details
