MCP6411 1 MHz Operational Amplifiers

Details: Written by: Newton C. Braga

September 2017 - Microchip's MCP6411 operational amplifiers for frequencies up to 1 MHz are in stock at Mouser Electronics. Output is rail-to-rail from 1.7 V to 5.5 V and the quiescent current is 50 UA.

Click here and see more details
