This circuit for the 11-meter band, operating at 29.255 MHz was found in a Radio Electronics dated June 1953. Note the low supply voltage. The modulatioin is 1.3 kHz.
Tunnel Diode Remote Control Transmitter (CB22572E)
- Details
- Written by: Newton C. Braga
