This interesting oscillator configuration was found in the October 1960 issue of Radio Electronics magazine. Frequency depends on L1 and the adjustable 750 pF capacitor. Average operating frequency is 21 MHz.
Vackar Oscillator (CB23979E)
- Details
- Written by: Newton C. Braga
