We found this circuit in the September 1971 issue of Radio Electronics magazine. The sensor is an LDR and R1 adjusts the sensitivity. A relay with the appropriate voltage can be used instead of a buzzer.
| Clique na imagem para ampliar |
Shadow Alarm (CB24163E)
- Details
- Written by: Newton C. Braga
