This is one of many possible circuits for the LM3914 IC as an audio indicator. The trim pot has typical values between 10k and 100k depending on the audio signal strength. The circuit is from a Radio Electronics from February 1981.
LM3914 Audio Indicator (CB24686E)
- Details
- Written by: Newton C. Braga
