At each touch of the sensor this counter based on circuit 4017 advances one LED. The circuit can be used for didactic or experimental purposes. The trim time adjustment is done by trimpot. The circuit must be powered by batteries or battery. Never use power supply without transformer.
| Clique na imagem para ampliar |
