This circuit is from European 90s documentation. The integrated circuit used is not very common today. The circuit works with 10 mV to 10 V input voltages and the output frequency range is 10 Hz to 10 kHz.
Current to frequency converter (CB4816E)
- Details
- Written by: Newton C. Braga
