Automatic 555 Hand Flashlight (CB25504E)

Details
Written by: Newton C. Braga



When the power is cut off, this circuit keeps the flashlight on for a while, allowing it to be located. The circuit is from a Radio Electronics from September 1992.




| Clique na imagem para ampliar |
