3,000 W Dimmer (CB7207E)

Suggested by Philips in a 1970 publication, this circuit uses components from that time. No information is given about the trip transformer.

| Clique na imagem para ampliar |

Pulse generator (CB9074E)
Found in a 1964 Electronic Design, this circuit generates pulses based on an avalanche diode of...
Sine and Cosine Oscillator with the 741 IC (CB9513E)
This circuit generates sinusoidal and cosine signals of 2 kHz given basically by the values of C1...
Sinusoidal Oscillator (MSB013E)
This circuit produces low frequency sinusoidal signals. The circuit is a phase shift oscillator...
