We found this circuit in an American publication in 1973. The circuit generates a low frequency signal in a range determined by C according to the input voltage. The control voltage of this circuit can be between 10 mV and 20 V and the voltage of the power supply can vary in the range of 6 V to 12 V.
| Clique na imagem para ampliar |
