We found this configuration in documentation from the 1980s. It applies to almost any operational amplifier and in this version requires a symmetrical power supply.
| Clique na imagem para ampliar |
Operational Half Wave Rectifier (CB14840E)
- Details
- Written by: Newton C. Braga
