This circuit has a power stage with transistors that allows to obtain a current greater than that of the integrated used. It goes for integrated with other tensions. The 2N3055 transistor must have a heat sink.
| Clique na imagem para ampliar |
5 V x 1.5 A Regulator (CB15028E)
- Details
- Written by: Newton C. Braga
