x10 frequency multiplier (CB21078E)

Found in American documentation from the 1990s, this TTL circuit operates at frequencies typically up to 100 kHz. Input signals must be rectangular.

| Clique na imagem para ampliar |

fet infrared Modulator (CB14681E)
The circuit shown is from the Texas Instruments optoelectronics manual, applying to low power...
High Impedance 2 W Amplifier (CB6163E)
This circuit was found in a 1968 General Electric documentation. It has an input impedance of 2 M ohms...
Twin-T Rejector Filter 741 (CB25603E)
This filter that rejects a frequency range determined by the double-T was found in the August 1993...
