This simple configuration that appears elsewhere on our website was found in the October 1974 issue of Radio Electronics magazine. The transistor supports general-purpose equivalents. The frequency is given by R1 and C1.
Unijunction LED Flasher (CB24331E)
- Details
- Written by: Newton C. Braga
