RIAA Equalizer Amplifier (CB25696E)

Details
Written by: Newton C. Braga



This preamplifier circuit for turntable cartridges was found in the March 1994 issue of Electronics Now magazine. The circuit is suitable for magnetic cartridges.




| Clique na imagem para ampliar |
