Abracon ADUD Surface Acoustic Wave (SAW) Duplexer is a low-temperature co-fired ceramic (LTCC) duplexer supporting 746MHz to 756MHz and 777MHz to 787MHz bandwidths. The duplexer features a small 1.8mm x 1.4mm x 0.5mm package with low insertion loss and ripple deviation ratings. The ADUD series operates with a 60dB to 63dB typical isolation range and a ±5VDC max voltage rating. The Abracon ADUD SAW Duplexer is RoHS compliant and ideal for various applications, including wireless infrastructure, military, aerospace, radar systems, 5G wireless communications, microwave radio systems, and more.
