CMOS Oscillator up to 10 MHz (CB13817E)

Details: Written by: Newton C. Braga

This circuit uses NOR ports to generate signals up to 10 MHz, depending on the crystal. The supply can be done with voltages from 5 to 15 V and the signal generated is rectangular.
