The output transistors of this circuit can be TIP31 and TIP32. The other transistors admit equivalents such as BC547 for TR1 and BD136 for TR2. TR3 and TR4 can be BD135. The source must provide at least 1.5 A.
| Clique na imagem para ampliar |
30 W amplifier (CB13671E)
- Details
- Written by: Newton C. Braga
