Based on the LTC3862, this circuit consists of a DC-DC converter capable of operating with input voltages lower than the desired output. MOSFET admits equivalent.
| Clique na imagem para ampliar |
12 V x 3 A power supply (CB21617E)
- Details
- Written by: Newton C. Braga
