This circuit works both as a grid-dip (transistorized) and as an oscillator. The circuit is from a Radio Electronics from August 1968. The FET is of a type that is still common today. MPF102.
| Clique na imagem para ampliar |
Crystal dipper and oscillator (CB23926E)
