The frequency of this oscillator depends on the coil and the 10 nF capacitor. The circuit is from a Radio Electronics from August 1971. The transistor is general-purpose, and the supply voltage is between 6 and 9 V typically.
Signal Injector (CB24158E)
- Details
- Written by: Newton C. Braga
